Two Layers Plastic Pipe Machine Manufacturers PE Pipe Extrusion Machinery

Name: Two Layers Plastic Pipe Machine Manufacturers PE Pipe Extrusion Machinery
Brand: Wangyuan
Price: 39999 USD

Cheap Two Layers Plastic Pipe Machine Manufacturers PE Pipe Extrusion Machinery for sale

Brand Name : Wangyuan

Model Number : pe pipe line

Certification : SGS

Place of Origin : China

MOQ : 1 set

Price : 39999-48888usd

Payment Terms : TT , L/C

Supply Ability : 16 sets

Delivery Time : 60 days

Packaging Details : film

Name : PE Plastic Water Hydraulic Extruder

Warranty : 1 Year

Application : High quality water supply and drainage

extruder model : SJ75/33 single screw extruder with 55kw

extruder : SJ75/33 high speed single screw extruder

mould : 50-160mm three layers PE gas and water drainage

pipe : HDPE Pipe Flexible Polyethylene Pipe

motor : 120kw

Contact Now

Single Screw extruder HDPE PE PP Pipe Making Extruding Plastic Extruder Pipe Machine

Product Application

1.The pipes are extruded by the first extruder and then enter the twist form machine, at the same time the basket co-extrusion mould forms pipes' shape.

2.The pipes are based on high density PE as main raw material.

Process line

Raw material+master batches→mixing → vacuum feeding → material dryness → single screw extruder → basket co-extrusion mould → calibrator → spray vacuum calibration tank → spray cooling water tank → belt haul-off → single screw glue extruder → winder → winding roller forming → water cooler → pipe rack → finished product inspecting&packing

Main advantage

1.This kind of pipes have many advantages, such as corrosion resistant light, easy to fix, long time to use etc.
2.The pipes are widely used in high-way, municipal constructional, flats and so on.


  	 			Pipe Range(mm)
 			Extruder Model
 			Extruder power(kw)
 			Max.output(kg/h)

 			20-63
 			65/33
 			37
 			120

 			50-160
 			75/33
 			55
 			200

 			75-250
 			75/33
 			110
 			330

 			90-315
 			75/33
 			132
 			380

 			160-450
 			90/33
 			160
 			450

 			315-630
 			120/33
 			280
 			750

 			400-800
 			150/33
 			355
 			900

 			710-1200
 			120/33
 			280
 			1200

 			1000-1600
 			120/33
 			280
 			1500
